M20-70
Manual retractable bollard
The ALE M20-70 bollard manufactured by AMCO is a manually operated retractable mechanical bollard.
Made of steel, 20 cm in diameter and 70 cm high, the bollard is supplied with an installation casing. It is lowered by gravity and raised manually using the operating key, which acts as a lifting handle.
Compatible with emergency services access, the lock is integrated into the bollard frame to protect it from impact. The floor plate is made of steel and painted in RAL 7016, and the bollard is also available with a stainless steel sleeve.
A wide range of configurations is available, including RAL colours, seafront treatment, customised lock and anti-vandalism screws
M20-70
Height: 70 cm
Diameter: 20 cm
MAIN CHARACTERISTICS
Standard characteristics:
• Cylinder:
• Steel treated with zinc plating and epoxy powder coating Ø 20 cm - height 70 cm RAL 7016 colour
• Brush seal to prevent scratching on housing
• Class 2 reflective tape
• Flat bollard head
• Frame:
• Steel floor plate in RAL 7016 colour
• Lateral guide with HDPE sliders
• Operation:
• Preconfigured for use with captive key
• Lock positioned under the frame and protected in the event of impact
• 11 mm triangle lock release system (emergency services)
• Operated by a locking key which, once inserted in the bollard head, acts as a lifting handle, with gravity lowering system
• Automatic lock in high and low position
• Standards:
• NFP 98-310-compliant
• Dimensions compliant with the French Decree of 18/09/2012 on the technical specifications for accessibility of roads and public spaces
Optional features:
Security
• Anti-vandalism screws
• Secure lock head
Customisation
• Choice of RAL colours on bollard
• Choice of RAL colours on floor plate
• Paint with seafront treatment
TECHNICAL SPECIFICATIONS
- Finishes
RAL 7016
- Concrete foundation dimensions (LxDxH)
310 x 310 mm
- Overall dimensions (LxDxH)
700 mm / 200 mm
